TEHNICAL DATA:

Luminous flux-measured: 2100 lm (6x OSRAM LED). Theoretical: 2690 lm

Beam pattern: spot up to cca 250m long and 20m wide

Power: 30w

Operating voltage: 12-24v DC

Measures (length x height x depth:  150x41(54 with holder)x45. Other measures at picture

Connection: cable length 2000mm (2x0.5mm). Red wire is supply, black is ground.

Protection:  IP6K9K waterproof protection

Operating temperature: -40 do +65°C

Lens: PC-impact protection

Body: aluminium

Bracket: stainless steel 64mm wide with M10 bolt

Weight: 440

Approvals: E9, 10R, EMC

Warranty: 2 years

Article number: ALIENMINISPT
